Every unit goes through a load test and measurements to current standards. You receive the inspection report with the measurement results with the extended service package.
Item
What was checked
Power supply and protection
power cable, plug, protection devices, electrical measurements to the current standard
Arc under load
welding test at the duty cycle for the rated current, thermal protection trip
Wire feeder, cooler, torch
rollers, liners, feeder motor, cooler flow and tightness, torch consumables
Panel and functions
all modes and programs as described by the manufacturer
Housing and interior
cleaning, signs of use, condition of boards and fans
Service verdict
Condition BCondition B, signs of use
Checked in our workshop in Krotoszyn to the current standards.
Description
About this machine
EWM Wega 400 in the compact version has the four roll wire feeder built into the housing, so there is no interconnection cable to set up and the whole unit moves as one machine. It is a classic transformer and rectifier design for steady work on structural steel.
Main data:
welding current 400 A at 45 % duty cycle, 265 A at 100 %
mains supply 3 x 400 or 415 V, 50/60 Hz
24 voltage steps and three choke outputs for different arc dynamics
M100 panel with wire speed 1 to 20 m/min, 2T and 4T modes, spot and interval welding 0 to 2 s, creep start and burn back control
drive rolls fitted for 1.0 and 1.2 mm steel wire
The machine is used and shows normal marks of workshop service. Before sale it was checked in our own service workshop in Krotoszyn against current standards.
The price covers the first year of our basic service package. Used machines are sold without a commercial warranty. You get a VAT invoice and we ship on a pallet to any EU country. Companies in the EU with an active EU VAT number are invoiced at 0 % VAT.
Service package for this machine
annual inspection, priority response, replacement machine, discount on parts and wires
